OVERVIEW |
|
19" 27U Outdoor Cabinet Rack deep 80cm, compatible 19inch for all equipment.EG steel Thick 1.5mm for stand outdoor type, Use for Equipment active device 19" standard. The Cabinet is compliant with IP55 (Dust and water protection) or IP65 (Option) standard. One door lockable and dust, made from "CNC" Foam Gaskets" style high-quality grade for waterproof and dust |
Brand |
Bismon |
Model |
B1-WM27U-OUT85 |
Equipment Type |
Wall rack outdoor |
Size |
1343 mm x 800 mm x 500 mm (HighxWidthxDepth) |
Standard |
Compliant IP55, IP65 |
Color |
|
Material |
EG (Electro-Galvanized) Steel thick 1.5mm, High-Quality Grade |
Application |
The cabinet can support fiber distribution fiber optic, CCTV, IP Camera, Optical Amplifiers, broadband equipment |
Features |
• 19-inch support for rack style, 2 Pole standard Rack 27U (Option: add 2 Pole 19” Back side support shelve) |
|
• One door lockable by key and safe sealing and protection of equipment against water humidity and dust, made from “ CNC Foam Gaskets” |
|
style, not rubber style |
|
• Double folded gutter at door frame to increase rigidity and prevents water from entering while the door is opened |
|
• All screw or nut made of stainless steel |
|
• Can support rack-mount 1U or 3U patch panel fiber optic max capacity: 27U |
|
• Can support cable entry 5 port and 2 cable glands EG/PG29 |
|
• Can support cable management inside easy for use cable tie lock |
|
• Can support FAN 2x4” for airflow, 2 points (Top & Bottom Rack) Max:4 pcs, Option: for Filter FAN 2x4” double protect dust inside |
|
• Complete set tools for hang on pole and support 4 hole for wall type |
|
• Can support hinges provide 130 deg. door opening |
|
• Surface finished cabinet with epoxy-polyester coating |
|
• Can support hinges provide 130 deg. door opening. |
Option (Made to order) |
Material: SPCC Steel sheet 2.0mm, hot-dipped galvanized for all wall rack cabinet, Stainless, Aluminum |
- 19" Standard Rack - 27U High Cabinet Rack - Width 80 cm - Deep: 50 cm - Double folded gutter at door frame to increase rigidity and prevents water from entering while door is opened. - All screw or nut made of stainless steel - Hang on Electric Squre Pole in Thailand - Stand type for cabinet - Made from color outdoor type epoxy polyester coating - Cable Grand lock cable EG/PG29 - Support FAN 2x4" 2 point TOP & Bottom rack - The front door is waterproof, humidity and dustproof sealing made from "CNC foam Gaskets", good adhesion to coated surfaces, UL 50. - Can support hinges provide 130 deg. door opening service - Material made from (EG) Electro Galvanized Steel thick 1.5mm - Dimension: 1343mmx800x500mm) HxWxD
