Specification

Interface

Fixed port                                                                                     2*10G Base-X, 16*10/100/1000 Base-T

Management Port                                                                     Support console

Power interface                                                                          Phoenix terminal, dual power supply redundancy

LED Indicators                                                                             PWR Link/ACT LED

Cable type & Transmission distance

Twisted-pair                                                                                  0-100m?CAT5e,CAT6?

Monomode optical fiber                                                          20/40/60/80/100KM

Multimode optical fibre                                                            550m

Network Topology

Ring topology                                                                               Not support

Star topology                                                                                Support

Bus topology                                                                                 Support

Tree Topology                                                                               Support

Hybrid topology                                                                           Support

Electrical Specifications

Input voltage                                                                                DC36-75V/AC 100-240V 50-60HZ

Total Power consumption                                                        Non POE <36W?with POE<276W

PoE Support

PoE port                                                                                       1-16

PoE Protocol                                                                               802.3af?802.3at

Pin Assignment                                                                           1,2,3,6

PoE Management                                                                      Not support

Layer 2 Switching

Switching capacity                                                                     160G

Packet forwarding rate                                                             95.23Mpps

MAC address table                                                                     16K

Buffer                                                                                             12M

Forwarding delay                                                                        <10us

MDX/MIDX                                                                                    Support

Flow control                                                                                  Support

Jumbo Frame                                                                                Support 10Kbytes

Environment

Operating temperature                                                              -40?~+75?

Storage temperature                                                                   -40?~+75?

Relative humidity                                                                         5%~95% ?non-condensing?

Thermal methods                                                                         Fanless design, natural cooling

MTBF                                                                                              100,000 hours

Mechanical Dimensions

Product size                                                                                   440*245*44mm

Installation Method                                                                      Rack

Weight                                                                                             3.6KG

EMC&INGRESS PROTECTION

IP Level                                                                                             IP40

Surge protection of Power                                                           IEC 61000-4-5   Level 3?4KV/2KV??8/20us?

Surge protection of Ethernet port                                             IEC 61000-4-5   Level 3?4KV/2KV??10/700us?

RS                                                                                                           IEC 61000-4-3   Level 3 ?10V/m?

EFI                                                                                                          IEC 61000-4-4   Level 3 ?1V/2V?

CS                                                                                                           IEC 61000-4-6   Level 3 ?10V/m?

PFMF                                                                                                    IEC 61000-4-8   Level4?30A/m?

DIP                                                                                                         IEC 61000-4-11   Level3 ?10V?

EMI                                                                                                   CLASS A

ESD                                                                                                        IEC 61000-4-2   Level 4 ?8K/15K?

Free fall                                                                                             0.5m

Authentication

Authentication                                                                                   CCC/CE/FCC/RoHS

Accessories

Accessories                                                                                           Equipment, terminals, optional power adapter, instructions, product certification
