Power consumptionMax Power (w/o PoE): 32.7W Max Power (w/ PoE): 455W

Input voltage100-127 VAC / 200-240 VAC

Ports24x ports 10/100/1000BASE-T ports 4x 1G SFP ports

Latency1 Gbps: 1.5 μSec

Routing capabilitiesStatic

Switching capacity56 Gbps

Throughput41.6 Mpps

Memory and processorDual Core ARM Cortex A9 @ 1016 Mhz 8 GB DDR3, maximum, depending on model 16 GB eMMC

PoE capability370W Class 4 PoE/PoE+

Operating Temperature32°F to 113°F (0°C to 45°C) up to 5000 ft (1.5 km)
derate -1°C for every 1000 ft (305 m) from 5000 ft
(1.5 km) to 10000 ft (3.0 km)

Weight9.24 lbs

Weight4.2 kg

Minimum dimensions ( H x W x D)1.73 x 17.4 x 10.56 in

Minimum dimensions ( H x W x D)4.4 x 44.2 x 26.8 cm
