OVERVIEW

The B1-3630-SFP Series Gigabit Ethernet Media Converters with external power supply are designed to transmit and receive 10/100/1000Mbps data over optical fiber. The electrical interface will Auto-Negotiate to a 100 Mbps or 1000Mbps Ethernet rate without any adjustments. The optical interface operates at a 1000 Mbps Ethernet rate. Both are environmentally hardened to operate in extreme temperatures. LED indicators are provided for confirming equipment operating status.

Key Features

1. 10/100/1000Mbps Ethernet

2. 10/100/1000 BASE-T/TX electrical port

3. 1000 BASE-SX/LX optical port

4. Electrical port supports Auto-Negotiation for 100Mbps or 1000Mbps, full duplex or half duplex data.

5. Optical port supports 1000Mbps full duplex data

6. Automatic MDI/MDI-X crossover

7. Distances up to 2km for Multi mode;Up to 120km for Single mode

8. Voltage transient protection on all power and signal input.output lines provides Voltage transient protection on all power and signal input.output lines provides

9. No in-field optical adjustments required

10. LED Indicators

Applications

1. Access Control Systems

2. Building and Environmental Control Systems

3. Tamper Switch

4. 10/100/1000 Mbps Ethernet Media Converter

5. High Speed Computer Links

Standard Compliance

•  IEEE802.3 10BASE-T

•  IEEE802.3u 100BASE-TX

•  IEEE 802.3ab 1000Base-T

•  IEEE 802.3z 1000Base-SX/LX standards

•  IEEE802.3x Flow Control and Backpressure

เป็น Media converter ที่รองรับ Mini-GBIC transceiver module LC connector ได้ทั้งแบบ Single-Fiber และ Dual Fiber optic หรือ สามารถรองรับ transceiver ได้ทั้งแบบ Single-mode และ Multi-mode ขึ้นอยู่กับ ลักษณะการใช้งานจริง
