Input

Model
Capacity (VA/W)
Phase
Rated Voltage
Voltage Range
Frequency Range
Power Factor
Current THDi
Bypass Voltage Range

ECO Range
Generator Input

2000VA
1800W
Single Phase & Ground
200/208/220/230/240VAC
140-290V*
40Hz-70Hz (auto-detect)
>0.99 @100% load (Nominal Input Voltage)
<6% at 100% non-linear load
Bypass high voltage point : 230-264 Vac (Setting in LC, Default: 264Vac)
Bypass low voltage point : 170-230 Vac (Setting in LC, Default: 170Vac)
Same As The Bypass
Support

Output

Phase
Rated Voltage
Power Factor
?Voltage Regulation
Frequency - Utility Mode

                - Battery Mode

Crest Factor
THD

Wave Form

Single Phase & Ground
200/208/220/230/240VAC
0.9
??+/- 1% (Battery Mode)
50Hz or 60Hz (Synchronized to Mains)
50Hz-60Hz  +/- 0.02% Hz
3:1
< 3% with Linear Load
< 5% with non  Linear Load
Pure Sine Wave

Efficiency

AC Mode ( Full Load )
?Battery  Mode ( Full Load )
ECO Mode ( Full Load )

Up to 90%
>88%
?>94%

Battery

Voltage
Capacity (Standard Unit)
Back up Time
Recharge Time to 90%
Charging current    - Standard
                            - Special

48Vdc
12V/9Ah
Full load 5 min, 15-30 min (Depend on load), Long time depends on capacity of EBP
4 Hours recovery to 90% capacity (Typical)
1A
12A

Transfer Time

Utility to Battery; 0ms, Utility to Bypass <4ms

Protection

Overload   - AC Mode, Batt. Mode

                - Bypass Mode
Short Circuit
Overheat
Battery Low
Self-Diagnostics
EPO
Battery
Noise Suppression

105%~110%: UPS shuts down after 10mins, 110%~130%: UPS
shuts down after 1mins, >130%:UPS shuts down after 3 seconds
16A (input Breaker)
Hold Whole System
Line mode; Switch to Bypass; Battery Mode, shutdown UPS immediately
Alarm and Switch off
Upon Power On and Software Control
Shutdown UPS immediately
Advanced Battery Management
Compiles with EN962040-2

ALARM

Audible & Visual
Reading on the LCD

Line Failure, Battery Low, Overload, System Fault

Display

Status LED & LCD
Reading on the LCD

Input/Output Voltage, Frequency, Temperature, Load/battery Level, Charger, Load
Capacity, Battery Voltage, Overload, ECO, Warning, Bypass, Battery, Inverter, ETC.

Physical

Dimnsion (WxHxD) mm.
Weight (Kilogram)
Input Connection
Output Connection

External Battery Connection

440 x 86.5 x 696
18.1
IEC320 C14-10A
Universal x 6
IEC320 C19-16A x1
Anderson like PowerPole Modular connectors

Dimensions

WxDxH (mm.)

?144 x 209 x 399

Communication
Interface

Smart RS232/USB Port
Communication slot
RJ 45

Support Windows Family, Linux, FreeDSB, etc.
SNMP Card (independent to RS232)
Built-in Power Surge, Lightning Protection Device

Environment

Operating Temperature
Storage Temperature
Humidity
Attitude
Noise

0 °C - 40 ° C
-25  °C - +55 °C
0-90% non-condensing
<1500 m. (derating while > 1500m)
<50 dB (at 1 meter)

Standards

Safty
EMC

ISO

IEC/EN62040-1, IEC/EN60950-1
IEC/EN62040-2, IEC61000-4-2, IEC61000-4-3, IEC6100-4-4
IEC61000-4-5, IEC61000-4-6, IEC61000-4-8
ISO9001, ISO14001
