OVERVIEW

The B1-IPS31084PF-M series is a 10/100M industrial PoE fiber switch Multi-mode Dual fiber 2KM  independently developed by BISMON. It has 6*10/100M RJ45 ports and 2*155M SC slot port, Port 1-4 can support IEEE 802.3af/at standard PoE power supply, and single port PoE power reaches 30W. The maximum PoE output power is 60W(at-120W). As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to POE terminal equipment such as wireless AP, web camera, VoIP phone, industrial sensor through network cable, and meet the network environment that needs high-density PoE power supply. It is suitable for intelligent transportation, rail transit, electric power, mining, metallurgy and green energy. Industrial scenes such as construction set up a cost-effective and stable communication network.

Unmanaged model, plug and play, no configuration, easy to use.

FEATURE

10/100M TP/SC port, fast Ethernet

• All series support "10/100M RJ45 port and 155M SC fiber port Multi-mode 2KM" combination, which enables users to flexibly build networking to meet the needs of various scenarios.

• Support non-blocking wire-speed forwarding.

• Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.

Powerful port lightning protection, wide voltage input

• Contact discharge 8KV, air discharge 15KV; port lightning protection common-mode 4KV, differential mode 2KV;

• Industrial dual power input

• DC INPUT: 48V-57V, non-PoE DC INPUT: 12-48V

Intelligent PoE power supply

• 4*10/100Base-TX RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

• IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

• Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

Stable and reliable

• Low power consumption, no fan , aluminum casing.

• CCC,CE, FCC, RoHS.

• The user-friendly panel, it can show the device status through the LED indicator of PWR, Link ,PoE.

Unmanaged industrial PoE fiber switch with 6*10/100M RJ45 ports and 2*155M SC ports, Port 1-4 can support PoE IEEE802.3af/at. By default, the SC port 1310mm/2km Multi-mode dual-fiber module. It can support dual DC redundant power input and DIN rail mounting.
