OVERVIEW

B1-IPS33084PFM is a full Gigabit managed industrial PoE switch independently developed by BISMON. it has 4*10/100/1000M PoE ports and 4*100/1000M SFP fiber slot ports, port 1-4 can supports IEEE 802.3af/at standard POE power supply, single port POE power up to 30W, and the maximum POE output power is 60W (at-120W).  As a POE power supply device, it can automatically detect and identify the electrical equipment that meets the standard and supply power through the cable. It can supply the POE terminal equipment, such as wireless AP, network camera, network telephone, industrial sensor and so on, to meet the demand for high density PoE power supply network environment. It is suitable for intelligent transportation, rail transportation, electric power industry, mining mining, metallurgy and green energy construction and so on. A reliable communication network.

The B1-IPS33084PFM has the L2+ full network management function, support IPV4/IPV6 management, static route full line rate forwarding, security protection mechanism, ACL/QoS policy and VLAN, and is easy to manage and maintain. Support multiple network redundancy protocols STP/RSTP/MSTP (<50ms) and (ITU-T G.8032) ERPS(<20ms) to improve link backup and network reliability. When one-way network fails, communication can be quickly restored to ensure important Uninterrupted communication for applications. According to the actual application requirements, you can configure multiple application services such as PoE power management, port traffic control, VLAN division, and SNMP through the Web network management mode.

L2+ managed industrial PoE fiber switch with 4*10/100/1000M RJ45 ports and 2*100/1000M uplink SFP slot ports, Port 1-4 can support IEEE802.3af/at PoE. Support DC dual power supply input and DIN rail mounting.

FEATURE

Gigabit access, SFP fiber port uplink

 • All series support “Gigabit Ethernet port and Gigabit SFP port” combination, which enables users to flexibly build networking to meet the needs of various scenarios.

 • Support non-blocking wire-speed forwarding.

 • Support full-duplex based on IEEE802.3x and half-duplex based on backpressure.

Powerful port lightning protection, ultra-wide voltage input

 • Contact discharge 8KV, air discharge 15KV; port lightning protection common-mode 4KV, differential mode 2KV;

 • Industrial dual power input

 • DC INPUT: 48V-57V, non-PoE DC INPUT: 12-48V.

Intelligent PoE power supply

 • 4*10/100/1000Base-T RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios.

 • IEEE 802.3af/at PoE standard, without damaging non-PoE devices.

 • Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient and avoid overwork of the device.

 • PoE network management, realize PoE port power allocation, priority setting, port power status viewing, time scheduling, etc.

PoE network management and fast Ring function

 • IEEE802.1Q VLAN, flexible VLAN division and QinQ configuration.

 • QoS, Priority mode based on 802.1P, Port & DSCP, queue scheduling algorithm including EQU, SP, WRR & SP+WRR.

 • ALC, filter data packet through configuring matching rules, processing operation & time permission, and provide flexible and safe access control.

 • IGMP V1/V2 and IGMP Snooping.

 • ERPS/STP/RSTP/MSTP.

 • Static and dynamic aggregation.

Security

 • 802.1X authentication.

 • Port isolation, Storm control.

 • IP-MAC-VLAN-Port binding.

Stable and reliable

 • Low power consumption, fan-less design, aluminum shell.

 • CCC, CE, FCC, RoHS.

 • The user-friendly panel, it can show the device status through the LED indicator of PWR,SYS, Link, L/A, PoE.

One-stop remote control and management

 • Web management, CLI command line (Console, Telnet), SNMP (V1/V2/V3).

 • HTTPS, SSLV3, and SSHV1/V2.

 • RMON, system log, LLDP, and port traffic statistics.

 • CPU monitoring, memory monitoring, Ping test, and cable diagnose.
