The B1-SWSFP04F2 is a 10/100/1000Mbps adaptive gigabit Ethernet Fiber Switch. It has two 10/100/1000Mbps Ethernet ports and four 1.25Gbps fiber ports. Users can choose different SFP modules in need. It can extend the transmission distance; there are also many other advantages such as isolation protection, good data security, working stability, and easy maintenance.
Features
(1) Support the switch between 10/100/1000Base-T and 1000Base-SX/LX;
(2) 4*1.25Gbps full-duplex fiber ports and 2*1000M Ethernet ports with
auto-negotiation function;
(3) Support MDI/MDIX and half/full-duplex with auto-negotiation function;
(4) Each port has a complete LED Indicator light ;
(5) Support IEEE802.1d Spanning Tree;
(6) Support IEEE802.1q and VLAN division;
(7) Support high-performance QoS function on each port;
(8) Support 5-16V voltage input;
(9) Require no configuration and will instantly operate as soon as you power it up;
(10) Use Marvel chip, stable and reliable;
(11) Low power consumption chip with heat sink built in to ensure longtime efficient
operation.
Technical Specifications:
Standards
|
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX/FX
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-SX/LX
|
IEEE802.3x Flow control
IEEE802.1p QoS
IEEE802.1d Spanning Tree
IEEE802.1q VLAN
|
Certifications
|
CCC, CE, FCC, RoHS
|
Ethernet Port
|
Connector: RJ45
Data Rate: 10/100/1000M
Distance: 100m
UTP Type: UTP-5E or higher level
|
Fiber Port
|
Connector: SFP slot
Data Rate: 1.25Gbps
Optical Wavelength: 850nm/1310nm/1490nm/1550nm
Distance: 550m?100km
|
Performance
|
Processing Type : Store and Forward
MAC Table Size: 1K
Buffer Space: 1Mbit
Back bandwidth: 14G
Time Delay:?20μs
|
Power
|
Power type: external power supply
Input Voltage: AC100V?240V 50/60Hz
Connector: DC Socket
Working Voltage: 5V
Power Consumption: 1.8W?5W
|
Environment
|
Storage Temperature: -40?70?
Operating Temperature: -10?55?
Relative Humidity: 5-90% ( no condensation)
|
Warranty
|
1 year
|
Physical Characteristics
|
Dimension: 160×84×26mm
Weight: 0.30kg
Color: Metal, Black
|
