Introduction
SP006PH-10G is an in-line surge protector designed for preventing damage to PoE (Power over Ethernet) devices from high voltage surges.
Features
• Surge current up to 20KA
• Supports data rate up to 10Gpbs
• Supports Mid-Span and End-Span PoE
• Built-in two stage protection with GDTs and SIDACTORs
• Supports protection for both differential and common mode
• Response time less than 1ns
• IEC 61000-4-2, IEC61000-4-5, UL497B compliance
• Supports multiple mounting options (Wall/Rack mounting & Din-Rail)
Installation view
Bandwidth/ Distance
For 10G application, the maximum distance is 80M. SC&T uses COMMSCOPE CAT6a cable for testing, the data rate may be slightly compromised by connected equipment, cables, and connectors.
Caution
• This product is not water resistant. If it is desired for outdoor use, please install additional equipment for waterproof protection.
• Avoid using this product close to water places, or near high-temperature devices such as radiators, stoves, etc.
• Using standard and certified Ethernet CAT5e UTP/STP/FTP, CAT6 UTP cables is recommended.
• 10G full speed cannot be reached when the transmission distance is longer than 80M.
• Only the port marked “protected” can prevent your PoE device from surging, so we recommend using a SP006PH-10G for each of your PoE devices that need to be protected.
• Ensure the input port connects to a network cable as below
• To effectively protect your PoE device, please ensure the product is properly grounded.
• DO NOT connect the ground wire to the power wire.
• The ground resistance value should be less than 100Ω.
• The protection is not bi-directional, the protected device must be connected to the Protected Connector.
• To have the best performance, using high-quality CAT6a cables and RJ45 connectors is recommended.
Specification: SP006PH-10G
• Compliance: IEEE 802.3af PoE, IEEE802.3at(PoE+), IEEE802.3bt PoE+++,
Passive PoE Compatible, IEC 61000-4-2 Standard, IEC61000-4-5 Standard. UL497B
• Data rate: 10/100/1000/10000Mbps(10Gbps)
• Operation Voltage: < 58V
• Operating Current: 8A
• Surge Discharge Current: 20KA(8/20us)
• Peak Pulse Current: 200A(10/1000us)
• Protection Mode: Different and Common Mode
• Insulation Resistance: > 10000Ohm
• Capacitance(Line to Line): < 2.5pF
• ESD Protection: +- 30KV (Contact & Air)
Port & Interfaces
• Data Input: 1xRJ45
• Data Output: 1xRJ45
Ambient Temperature
• Operation: -40 to 70 C
• Storage: -40 to 90 C
• Max. Operating Altitude: 2000M
• Humidity: Up to 95%
Physical Characteristics
• Mounting: Rack-mount/Wall-mount/Din-Rail
• Dimensions: 50x80x32mm
• Weight: 160g
