OVERVIEW
Features:
• Performs a different function than grounding requirements.
• Protects equipment from high voltage surges from nearby lightning strikes.
• Two stage protection: under 1ns-90V, over 10ns-12V.
• Wide range of applications: CCTV/CATV system,
• Antenna of Television, FM receivers, video camera, monitors, multiplexers & Quad processor, VCR...etc.
• 3 pin terminals + F female to 4 pin terminals + F female.
• Two stage protection, AC/DC 130V, AC/DC12V
• Max power input AC 40V(MAX), DC 56V(MAX).
• Max current up to 2Amp.
Specification:
• Surge Protection Attack Time: 1 ns
• Maximum Surge Voltage: 4 KV
• Surge Life: 300 surges of 100 Amps
• Normal Resistance Across Coax: 10,000 M ohm
• Surge Resistance: Approx. M ohm
• BAND PASS: 0~1 GHZ
• Power Passing Capability: 130V DC / AC, 65 Vrms at 10 Amps
• Insertion Loss: Less than 0.2 dB
• Return Loss (75 ohms): 16dB
• Power IN Put: AC 40V(MAX), DC56V(MAX)
• Connectors: F, Terminal
• Dimension (mm): 87x67x27
• Weight (g): 136
